2.5 GIGABIT 30W POE INJECTOR
LBW-480625A-2.5G
2.5 Gigabit PoE injector supporting 10/100/1000/2500Base-T with 30W output over four pairs, 48V output, 90–264VAC universal input, FCC Class B / UL / TUV certified, and intelligent adaptive power delivery
Get a quote2.5GbE PoE injector delivering 30W over four pairs with plug-and-play installation
The LBW-480625A-2.5G is a professional-grade 2.5 Gigabit PoE injector delivering 30W of power over four pairs to modern network devices. Supporting 10/100/1000/2500Base-T applications, it provides a 48V ±5% output at up to 625mA from a universal 90–264VAC input — making it compatible with power grids worldwide. Plug-and-play installation requires no configuration, and the injector intelligently delivers only the required power to low-power devices.
Built for reliability in demanding environments, the LBW-480625A-2.5G operates from -20°C to 60°C with free air convection cooling and an ultra-low standby power of under 0.2W. Triple protection against overvoltage (latch-off), short-circuit, and overcurrent (both auto-recovery) ensures long-term safe operation. Certified to FCC Class B, CISPR22 Level B, UL 60950-1/LPS, CSA C22.2 No. 60950-1, and TUV EN60950-1, it is ready for professional network deployments.
Highlights & benefits
30W PoE over Four Pairs
30W output over four pairs powers the latest generation of 802.3at PoE devices with a single Ethernet cable.
2.5 Gigabit Ethernet
Full 10/100/1000/2500Base-T support ensures maximum throughput for Wi-Fi 6 access points and high-speed CPEs.
Universal 90–264VAC Input
Wide-range AC input works with any power grid worldwide — no adapter or voltage converter required.
Triple Protection
Overvoltage (latch-off), short-circuit, and overcurrent (auto-recovery) protection for long-term reliable operation.
FCC / UL / TUV Certified
Certified to FCC Class B, UL 60950-1/LPS, CSA C22.2 No. 60950-1, and TUV EN60950-1 for professional deployments.
Plug-and-Play, Ultra-Low Standby
Zero-configuration installation and under 0.2W standby power minimise setup time and energy costs.
Gallery
Key characteristics
| Input Voltage | 90–264 VAC |
| Input Frequency | 50–60 Hz |
| Output Voltage | 48V ±5% |
| Output Current | 625mA minimum |
| Output Power | 30W over four pairs |
| Ethernet Speed | 10/100/1000/2500Base-T (2.5GbE) |
| Standby Power | <0.2W (no load) |
| Efficiency | 75%–85% |
| Holdup Time | 16ms typical @ rated load, 115VAC |
| OVP | Latch off |
| SCP / OCP | Auto recovery |
| Cooling | Free air convection |
| Operating Temp. | -20°C to +60°C |
| Storage Temp. | -20°C to +85°C |
| EMI | FCC Class B, CISPR22 Level B |
| EMS | EN61000-4-2/-3/-4/-5/-6/-11 |
| Safety | UL 60950-1/LPS, CSA C22.2 No. 60950-1, TUV EN60950-1 |
